Heavy metal tungsten alloy face mill with 4 or 5 PCD cutting edges for machining cutting tools of composite material. This tool is designed for high speed facing operations

• CFRP
• Aluminium
• Lightweight metals

Technical features:

• Material: Tungsten alloy body (up to 32.0 mm)
• Case hardened body (over 32.0 mm)
• PCD cutting edges: 4/5
• Helix angle: 0° – 10°
• Cutting tolerance: +/- 0.02
• Balance: G2.5 < 1 gr/mm
• Shank form: HSK20C
• Diameters: from 25.0 to 50.0 mm on request
• The HSK cone grants exceptional axial and radial accuracy
• "Easy Flow"
• Profiled “Glide Cut” edges to reduce cutting pressure
• Available up to 40.0 mm diameters end-cut-to-centre design
• Customised multi-role cutters on request
