Heavy metal tungsten alloy face mill with 4, 5 or 8 PCD cutting edges for machining cutting tools of composite material. This tool is designed for high speed facing operations

• CFRP
• Aluminium
• Lightweight metals

Technical properties:

• Material: Tungsten alloy body (up to 32.0 mm)
• Case hardened body (over 32.0 mm)
• PCD cutting edges: 4/5/8
• Helix angle: 0° – 10°
• Cutting tolerance: +/- 0.02
• Balance: G2.5 < 1 gr/mm
• Shank form: HA (DIN 6535)
• Diameters: from 25.0 to 80.0 mm
• “Easy-Flow”
• Profiled “Glide Cut” edges to reduce cutting pressure
• Through coolant are available, only with Basic and Reach tool-holders
• Available up to 40. mm diameters end-cut-to-centre design
• Customised multi-role cutters on request
